Minikube: Small Cluster, Big Picture

Minikube in a nutshell

Minikube lets you run a local Kubernetes cluster on your machine. For context, Kubernetes is an open-source system for automating the deployment, scaling, and management of containerized applications. Minikube, however, is lightweight, quick to set up, and perfect for testing and development.

It simulates a real Kubernetes environment, allowing you to build and test applications locally before deploying them to a larger cluster. By creating a single-node cluster, Minikube helps you mirror a full Kubernetes setup. It uses virtual machines or Docker containers to keep the process smooth and simple.

Minikube setup

Installation of Minikube

1

sudo install minikube-linux-amd64 /usr/local/bin/minikube && rm minikube-linux-amd64

Using kubectl with Minikube

After minikube start, kubectl is configured to talk to the Minikube cluster automatically. If you already have kubectl installed locally, just use it normally. If not, Minikube includes its own kubectl, so you can run commands through minikube kubectl – … instead.

Example:

1
2
3
4
5

# normal usage if kubectl is installed
kubectl get nodes

# fallback if kubectl is not installed locally
minikube kubectl -- get nodes

If you do not have local kubectl, you can also make a quick alias for convenience:

1	alias kubectl='minikube kubectl --'

kubectl auto-completion

If you want to enable kubectl auto-completion on Ubuntu, you can run:

Install bash-completion if you haven’t already:

1
2

sudo apt update
sudo apt install -y bash-completion

Then add kubectl completion to your shell:

1
2

echo 'source <(kubectl completion bash)' >> ~/.bashrc
source ~/.bashrc

When you start typing a kubectl command, you can now press Tab to see available options and complete commands.

Example:

1

kubectl get n<TAB><TAB>

This will auto-complete to:

1

kubectl get nodes

or show you other options if there are multiple matches.

Start a local cluster

Start a local Kubernetes cluster with Minikube by running:

1

minikube start

Then in order to check if the cluster is running properly and healthy, run these commands:

1. minikube status to check the status of the cluster. This will return something like:

1 2 3 4 5 6

minikube type: Control Plane host: Running kubelet: Running apiserver: Running kubeconfig: Configured

2. kubectl cluster-info to get cluster information. This will return something like:

1 2	Kubernetes control plane is running at https://<IP_ADDRESS>:8443 CoreDNS is running at https://<IP_ADDRESS>:8443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

3. kubectl get nodes to see the nodes in your cluster. We want to see READY state here on the node. You should see something like:

1 2	NAME STATUS ROLES AGE VERSION minikube Ready control-plane 113m v1.35.1

Build app image into Minikube

cd to your project root and make sure you have a Dockerfile for your app. Then run;

1

minikube image build -t my-app:latest -f app/Dockerfile .

my-app:latest name and app/Dockerfile can be different for future projects, change them.

Create deployment.yaml and service.yaml files

Create deployment.yaml and service.yaml files under your project, preferably under any kubernetes folder like k8s/

deployment.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
spec:
  replicas: 1
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
        - name: my-app
          image: my-app:latest
          imagePullPolicy: Never #this forces minikube to use local image
          ports:
            - containerPort: 8000

How to think about it:

• Deployment says “keep this app running.”
• replicas: 1 matches your subtask.
• matchLabels and labels must match exactly.
• containerPort: 8000 matches your Uvicorn port.

service.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

apiVersion: v1
kind: Service
metadata:
  name: my-app-service
spec:
  type: NodePort
  selector:
    app: my-app
  ports:
    - protocol: TCP
      port: 8000
      targetPort: 8000

How to think about this:

• Service gives your Pod a stable way to receive traffic.
• selector must match the Pod label from the Deployment.
• targetPort: 8000 sends traffic to the app inside the container.
• type: NodePort exposes it so your browser can reach it through Minikube.

In short;

• deployment.yaml -> Defines how your application pods run and are managed (replicas, updates, container image).
• service.yaml -> Exposes your pods to the network so they can be accessed internally or externally.

Also quick mnemonic to lock it in:

• Deployment -> D for Do: ‘Do run my pods’ (manages pods and replicas).
• Service -> S for See: ‘See my app’ (lets the app be accessed).

Super short, easy to recall: Deployment = Do, Service = See.

Applying manifests

Apply the manifests by running:

1
2

kubectl apply -f k8s/deployment.yaml
kubectl apply -f k8s/service.yaml

Verify everything done so far

Verify everything using

1
2
3
4
5
6
7

kubectl get deployments

kubectl get pods

kubectl get services

kubectl rollout status deployment/my-app

In short, here is what to expect in good and bad scenarios:

kubectl get deployments

• Good: Shows the Deployment exists and all desired replicas are available.

  1 2	NAME READY UP-TO-DATE AVAILABLE AGE my-app 1/1 1 1 10m

• Bad: The Deployment exists, but not all replicas are available yet.

  1 2	NAME READY UP-TO-DATE AVAILABLE AGE my-app 0/1 1 0 10m

kubectl get pods

• Good: Pod is running and ready.

  1 2	NAME READY STATUS RESTARTS AGE my-app-6f9d8c7b6b-abcde 1/1 Running 0 10m

• Bad: Pod is not healthy yet, for example CrashLoopBackOff or Pending. Kubernetes documents Pending as an early Pod phase and separately discusses debugging crashing Pods.

  1 2	NAME READY STATUS RESTARTS AGE my-app-6f9d8c7b6b-abcde 0/1 CrashLoopBackOff 5 10m

  or

  1 2	NAME READY STATUS RESTARTS AGE my-app-6f9d8c7b6b-abcde 0/1 Pending 0 10m

kubectl get services

• Good: Since your manifest uses type: NodePort, the Service should show up as NodePort, not ClusterIP.

  1 2	NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE my-app-service NodePort 10.103.243.150 <none> 8000:3xxxx/TCP 10m

• Bad: Service was not created.

  1	No resources found in default namespace.

kubectl rollout status deployment/my-app

• Good: Rollout completed successfully. The kubectl rollout status command watches the latest rollout until it finishes.

  1	deployment "my-app" successfully rolled out

• Bad: Rollout is still in progress or stuck.

  1	Waiting for deployment "my-app" rollout to finish...

Troubleshooting

• Pod logs: kubectl logs <pod-name>
• Describe pod: kubectl describe pod <pod-name>
• View events: kubectl get events

Accessing the app

To access the app, run:

1

minikube service my-app-service --url

This will give you a URL like http://<IP_ADDRESS>:<PORT>. Open that URL in your browser to see your app running.

Changed anything?

If you change the app code, rebuild the image into Minikube (while using local image)

1. Rebuild the image into Minikube:

1

minikube image build -t my-app:latest -f app/Dockerfile .

2. Restart the Deployment so it makes a new Pod from that rebuilt image:

1

kubectl rollout restart deployment/my-app

3. Wait until rollout finishes:

1

kubectl rollout status deployment/my-app

4. Test again with new changes

1

minikube service my-app-service --url

I think the mental model of this process can be like;

• Change Python code -> rebuild image
• Change image -> restart Pod/Deployment
• Change Kubernetes YAML -> kubectl apply -f …

BUT if you changed the YAML itself;

1
2
3

kubectl apply -f k8s/deployment.yaml

kubectl apply -f k8s/service.yaml

For example;

• If you changed replicas, image name, env vars, ports -> kubectl apply -f …

• If you changed only app code in source code file -> rebuild image, then rollout restart

In short;

After code changes:

1. Rebuild image
2. Restart deployment
3. Wait for rollout
4. Test service

After YAML changes:

1. kubectl apply -f …
2. Check pods/services
3. Test again

Stop the cluster when done

Stops the underlying VM or container, but keeps the cluster data so you can start it again later.

1

minikube stop

You can expect output like this:

1

Stopping "minikube" in ...

Stop a specific cluster

1

minikube stop -p <profile-name>

1
2
3
4

minikube stop -p my-cluster
✋  Stopping node "my-cluster"  ...
🛑  Powering off "my-cluster" via SSH ...
🛑  1 node stopped.

Note: To see existing clusters and get profile name, run minikube profile list and find the name of the cluster you want to stop.

1
2
3
4
5
6
7

minikube profile list
┌────────────┬────────┬─────────┬──────────────┬─────────┬────────┬───────┬────────────────┬────────────────────┐
│  PROFILE   │ DRIVER │ RUNTIME │      IP      │ VERSION │ STATUS │ NODES │ ACTIVE PROFILE │ ACTIVE KUBECONTEXT │
├────────────┼────────┼─────────┼──────────────┼─────────┼────────┼───────┼────────────────┼────────────────────┤
│ minikube   │ docker │ docker  │ <IP_ADDRESS> │ v1.35.1 │ OK     │ 1     │ *              │                    │
│ my-cluster │ docker │ docker  │ <IP_ADDRESS> │ v1.35.1 │ OK     │ 1     │                │ *                  │
└────────────┴────────┴─────────┴──────────────┴─────────┴────────┴───────┴────────────────┴────────────────────┘

ACTIVE PROFILE means: when you run a minikube command without choosing a profile, Minikube will use this cluster by default.

ACTIVE KUBECONTEXT means: when you run a kubectl command, kubectl is currently connected (or talking) to this cluster.

However these do not always have to match. Minikube can default to one cluster, while kubectl is connected to another.

Restart the cluster when needed

1

minikube start

Restart a specific cluster

1

minikube start -p <profile-name>

Delete the cluster when done

Removes the cluster VM or container and its associated files.

1

minikube delete

You can expect output like this:

1

Deleting "minikube" in ...

Delete a specific cluster

1

minikube delete -p <profile-name>

1
2
3
4
5

minikube delete -p my-cluster
🔥  Deleting "my-cluster" in docker ...
🔥  Deleting container "my-cluster" ...
🔥  Removing /home/nedim/.minikube/machines/my-cluster ...
💀  Removed all traces of the "my-cluster" cluster.

Conclusion

This should be a good starting point for me to quickly recall how to use Minikube for local Kubernetes development. The key is to understand the basic workflow which is build the image, define the Kubernetes manifests, apply them, verify everything, and troubleshoot if something goes wrong. With practice, this process will become second nature.
